Pellet Stove Auger Motor Shade Pole Gear box 5.5W 120VAC 60Hz 2.4
RPM
The Auger Motor shade pole gear box is designed for use in pellet
stove. It has a rated power of 5.5W, 120VAC and the 60Hz, the
rotating speed of 2.4 RPM. The motor is equipped with a gear box, which is responsible for
reducing the motor's speed and increasing its torque. The gearbox
helps regulate the speed at which the auger rotates, ensuring
precise pellet feeding.
Quick Review:
| Product Name: | Pellet Stove Auger Motor Shade Pole Gear Box 5.5W 120VAC 60Hz 2.4 RPM | Model Type:: | MHSGM49TYZ |
|---|---|---|---|
| Rated Voltage/Frequency: | 120Vac/60Hz | Current(A): | 0.05 |
| Input Power(W): | 5.5 | Output Speed(RPM)(W): | 2.4 |
| Hi-Pot TEST: | 1500vac50hz,1Ma,1s | Bearing Type: | Sleeve |
| Insulation Class: | B | Protect Method: | Z P |
| Agency: | CCC | Appliction: | Pellet STOVE |
For detail information, please contact us for catalogue, thanks!
Production Description:
1. With synchronous motor,small-volume,high efficiency
2. Powerful, Quiet, Energy Efficient .
3. Variety of mounting patterns and options available.
4. The rotation can be reversible :CW & CCW
5. Typically used for conveying pellets in pellet stoves.
|
|
