Shanghai MH Electric Co., Ltd.
3 Years
| Ask Lasest Price | |
| Brand Name : | MH motors |
| Model Number : | MH84-84544 |
| Certification : | NA |
| Price : | Negotiable(EXW) |
| Payment Terms : | T/T |
| Supply Ability : | 1200PCS/day |
| Delivery Time : | 35 work days |
China 3.3" frame 157W AC shade pole electric blower motor for strong torque
The motor is an AC electric motor designed with a 3.3-inch frame. It has a rated power of 157W, delivering excellent power performance. One of the notable features of this motor is its strong torque output, making it particularly suitable for applications that require high torque. This motor is commonly used in applications that involve larger startup loads, such as in strong exhaust systems, commercial kitchen equipment blowers, and hot air circulation.
Quick Review
| Product Name: | China 3.3" Frame 157W AC Shade Pole Electric Blower Motor For Strong Torque | Rated Voltage/Frequency: | 115V60Hz |
|---|---|---|---|
| Current(A): | 2.09 | Input Power(W): | 157 |
| Output Speed(RPM): | 1500 | Hi-Pot TEST: | 1500vac50Hz,1mA,1S |
| Bearing Type: | Sleeve Bearing | Insulation Class: | B |
| Agency: | NA | Application: | OVEN,FIREPLACE |
| Protect Method: | TP | Output Torque(IN.OZ): | 37.6 |
Production Description:
1. Has a diameter of 3.3 inches and is made of high-quality electrical steel material.
2. It is typically used in applications such as machinery and fan blades.
3. Multiple installation structures are available for selection.
4. Various connection methods are available, including wire or quick terminal structures.
5. Multiple shaft sizes are available for selection.
6. Ball bearings or oil-impregnated bearings can be chosen.
7. The motor features a high-strength steel housing.
MH brand Shaded pole 3.3-inch diameter HVAC AC motors have a low starting torque that provides a smooth and quiet start up while being more economical than other types of replacement motors used in blower applications such as bathroom fans and range hoods.
Our Products Advantage:
A.100% testing after each process and final testing before packing, all raw material is good quality. 100% cooper wire, Cold-rolled silicon steel sheet, good quaility shafts, bearings, stators, fan, fan covers etc.
B.High efficiency.
C. Low noise.
FAQ
Q1- What is the warranty of the motors?
The warranty is 18 months from the shipping date.
Q2- Can you design and make the motor as required?
Yes, we provide both ODM and OEM products.
Q3- What is your advantage?
Besides the good quality and the competitive price, we offer the short lead time and quick response.
Q4- What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. The term can be
negotiated for long-term business.
Q5- How to get the accurate quotation?
The accurate price will be quoted after the specification and mounting dimension of the motor are checked.
Q6- Do you test all products before the delivery?
Yes, all products are tested OK before the delivery
Q7- Do you have any MOQ for motors?
Usually our MOQ is one pallet. But we accept the small quantity for the trial order.
Q8- Do you have other products?
Yes, besides the shade pole motors and blowers ,we also offer OEM production for some industrial motors such as single phase AC motor, 3 phase industrial motor, stainless steel motor, BLDC fan motor etc... And we offer the sourcing service for other products required.
Thank you very much for viewing this page
Sincerely looking forward to our cooperation!
|
|
